Weld on hook 10000kg is designed to be welded on iron and provide an attachment point for lifting.
Technical details:
| WLL in kg | Dimensions in mm | Weight
kg/piece |
|||||
| A | B | C | E | G | L | ||
| 1120 | 25 | 76 | 59,5 | 20 | 25 | 97 | 0,48 |
| 2000 | 26,5 | 92 | 65 | 22 | 34 | 114 | 0,85 |
| 3000 | 29 | 106 | 75 | 24 | 36 | 129 | 1,12 |
| 5000 | 34,5 | 130 | 92 | 30 | 45 | 171 | 2,50 |
| 8000 | 34,5 | 135 | 98 | 39 | 51 | 177 | 3,20 |
| 10000 | 51 | 171,5 | 134,5 | 39 | 53 | 223 | 5,20 |
All images are symbolic.
